Cold-hot dual-purpose screw oil press
Cold-hot dual-purpose screw oil press
Cold-hot dual-purpose screw oil press
Model 6YL-100 cold-hot multi-functional screw press is a new product developed by our company. It can press soybean, peanut, tea seed, sesame, sunflower, rapeseed, cottonseed, flaxseed, corn germ and other raw materials. The equipment integrates infrared heating, automatic temperature control and precision filtering system. It adopts multi-stage pressing technology. Secondly, the raw material is poured into the machine to press out the pure oil, which can be eaten directly.It is suitable for small oil factories to be squeezed, sold and processed,easy to operate and high efficiency.
Contacting via phone: +86-371-88915968

share us:
Description
Working principle
Cleaning, quenching, crushing, softening, rolling, steaming and pre-pressing. Among them, the pretreatment of cottonseed should have processes such as depilation and shelling.
Type: 6YL-100
Screw speed: 30-40 rpm
Gearbox rotation ratio:15/40×15/55=1:9.78
Processing capacity:150~250kg/h
Weight:870kg
Power: Host 7.5KW + Vacuum Pump 1.1KW + Heater 3KW
Advantage
Product characteristics:
1
It has a wide range of uses. It can press more than 20 kinds of oil crops, such as peanut, sesame, rapeseed, soybean, sunflower, flax, etc.
2
Multistage pressing. The residual oil rate of the material was further reduced, and the quality of oil and cake was increased.
3
Automatic temperature control. There is no need to preheat the mill, and the crude oil can be automatically heated to facilitate oil refining, which can be squeezed all the year round.
4
Vacuum filtration. With portable continuous refiner, oil residue can be separated quickly, colloidal impurities such as phospholipids can be removed, the treated oil can not foam, meet the edible oil standard, and can be directly filled and sold.
5
Large capacity.It can handle 150 to 250 kg of raw materials per hour.
6
The equipment has good material quality and long service life.
Application
Pretreatment suitable oil:
soy
soy
Sunflower Seeds
Sunflower Seeds
Peanut
Peanut
Rice bran
Rice bran
Rapeseed
Rapeseed
Cottonseed
Cottonseed
