The Oil conditioning tower is mainly composed of three parts: modulation body, wind network system, automatic display and control system. According to the difference of output and moisture content of raw materials, the quenching and tempering tower is composed of 9-13 layers, each layer is generally 1 m high, and the hot air layer is equally stratified in the quenching and tempering tower.The main body of the tower is composed of feed section, steam heating section, hot air drying section and transmission discharging section.Generally,A material equalizer is installed in the feeding section so that the material can enter the quenching tower evenly. A high level gauge can also be installed to ensure alarm at high level, or interlock with the transmission mechanism of feeding and discharging, and automatically adjust the speed of feeding and discharging to ensure a certain amount of material.Steam layer generally adopts stainless steel elliptical tubes with large heat transfer area and good heat transfer, and the arrangement of upper and lower layers of tubes is exactly 90 degrees each other; hot air layer adopts corner boxes used in popular mixed-flow soybean drying tower; transmission and discharging section consists of 4-6 groups of transmission and discharging sprockets and rotary valves.

The main function of oil conditioning tower is to adjust the moisture and temperature of the immersed material to achieve good leaching effect. The oil conditioning tower manufactured by our company has the advantages of stable performance and adjustable performance. It can be used to provide steam heating and conditioning for soybeans, rapeseed or other free-flowing grain products.
